AJAX HUB 2 PLUS SECURITY CONTROL PANEL /4G/ ETHERNET WIFI WITH SUPPORT FOR PHOTO VERIFICATION WHITE

The Ajax Hub 2 Plus (HUB 2 PLUS-W / Hub 2 Plus White) is a flagship, enterprise-grade wireless security control panel engineered for high-risk commercial facilities, industrial warehouses, educational institutions, retail chains, and luxury estates. Designed to guarantee uninterrupted connectivity under the most challenging network conditions, the Hub 2 Plus features a quadruple-channel redundant communication architecture: two independent 2G/3G/4G (LTE) SIM card slots, dual-band Wi-Fi (2.4 GHz /5 GHz), and a dedicated Fast Ethernet port, ensuring real-time event reporting and cloud synchronization even if three network paths fail simultaneously.

Operating with two proprietary radio protocols—Jeweller for high-speed bi-directional telemetry and command delivery (up to 2,000 meters / 6,550 ft) and Wings for high-speed encrypted visual photo transmission—the hub delivers snapshot confirmations from MotionCam detectors in under 9 seconds to verify break-ins and eliminate false dispatches. The Hub 2 Plus manages up to 200 wireless devices, 100 surveillance cameras or RTSP video streams, 200 users, 25 security partitions (groups), and up to 64 automation scenarios for scheduled or alarm-triggered building automation. Housed in a clean, minimalist enclosure with an internal 15-hour rechargeable Li-Ion backup battery, SmartBracket mounting plate with integrated tamper switch, and zero-configuration cloud pairing via QR codes, the Hub 2 Plus represents the benchmark in modern, Grade 2 wireless security.

✅ Key Features

• Quadruple Redundant Communication: Combines Fast Ethernet, Dual-Band Wi-Fi (802.11 b/g/n), and 2× Micro-SIM slots supporting 4G/LTE, 3G, and 2G cellular networks with sub-second failover.

• Wings Visual Alarm Verification: Receives encrypted visual photo series from MotionCam detectors in less than 9 seconds over long distances without Wi-Fi dependence.

• Jeweller Long-Range Protocol: Encrypted, frequency-hopping radio link operates up to 2,000 m (6,550 ft) in open space with instant 0.15-second command delivery.

• High System Capacity: Supports up to 200 connected wireless peripherals, 25 independent security groups (partitions), 200 authorized users, and 5 range extenders (ReX / ReX 2).

• Extensive Video Surveillance Integration: Integrates up to 100 IP cameras and DVR/NVR channels via standard RTSP streaming or native manufacturer SDKs (Uniview, Hikvision, Safire).

• 64 Advanced Automation Scenarios: Triggers smart plugs, relays, and water shutoff valves automatically based on alarms, arming state changes, temperature thresholds, or set schedules.

• 15-Hour Li-Ion Backup Battery: Internal rechargeable lithium-ion battery maintains uninterrupted operation during primary power blackouts.

• Anti-Sabotage & Tamper Protection: Features dual tamper detection against casing opening and wall detachment, along with active radio frequency jamming detection and channel switching.
