Ajax Hub BP (Jeweller) – Battery-Powered Wireless Security Control Panel with Photo Verification Support (White, 9NA)

Product Overview

The Ajax Hub BP Jeweller (SKU: 126865.263.WH3, 9NA region frequency) is an ultra-low-power, battery-powered central security control panel engineered specifically for off-grid properties, vacant buildings, remote construction sites, agricultural facilities, storage containers, and assets lacking stable mains electrical power. Operating exclusively on battery power (internal or external dry cells/rechargeable packs from 4.2 to 16 VDC), Hub BP delivers full-scale commercial protection and supports MotionCam visual alarm verification.

Equipped with dual 4G (LTE) micro-SIM slots for carrier redundancy in cellular-only environments, Hub BP communicates over the encrypted Jeweller (events and alarms) and Wings (photo series transmission) wireless protocols across distances up to 2,000 meters (6,550 ft). Running on real-time OS Malevich with intelligent power-saving operational modes, Hub BP can provide up to several years of autonomous operation on battery power, coordinating up to 100 connected Ajax devices and delivering Grade 2 anti-tamper security in a clean matte white finish.

Key System Features & Functionality

• Off-Grid Autonomous Battery Operation: Engineered with an ultra-low-power consumption architecture to run entirely on external or internal battery packs (4.2-16 VDC, including Zinc-Air or LiFePO4 cells) for months or years without mains AC power.

• Dual 4G/LTE Cellular Redundancy: Features 2 x Micro-SIM slots supporting 4G (LTE), 3G, and 2G with instant carrier failover to guarantee uninterrupted alarm transmission in remote areas.

• Visual Alarm Photo Verification: Full support for the high-speed Wings radio protocol to transmit animated photo series from indoor and outdoor MotionCam detectors in under 9 seconds.

• Large Device Capacity: Manages and coordinates up to 100 Ajax wireless devices, 25 MotionCam detectors, 9 security groups, and 50 individual users.

• Ultra-Fast Alarm Transmission: Relays intrusion, fire, and flood alarm signals to users and Central Monitoring Stations (CMS) via cellular push notifications, SMS, or phone calls in 0.15 seconds.

• Proprietary Encrypted Radio Protocols: Two-way encrypted Jeweller & Wings protocols operate up to 2,000 meters (6,550 ft) with anti-jamming frequency hopping.

• Intelligent Power Management Scenarios: Configurable wake-up intervals, cellular power-saving schedules, and battery discharge monitoring prolong field battery life.

• Grade 2 Sabotage & Tamper Defense: SmartBracket mounting base includes an integrated tamper switch that reports unlatching or wall detachment immediately.
