HM-130 – Universal Waterproof Aluminum Junction Box for Dome & Bullet Cameras (133 mm x 52 mm / 5.23" x 2.05")

Product Overview

The HM-130 (Dimensions: 133.0 mm x 52.0 mm / 5.23" x 2.05") is a universal heavy-duty, weatherproof camera mounting junction box engineered specifically for dome, turret, and bullet security cameras. Designed for commercial, residential, and industrial video surveillance installations, this deep-base junction box provides an expansive, sealed internal cavity to conceal and protect sensitive camera pigtails, RJ-45 network terminations, DC power plugs, and video baluns from outdoor weather exposure and physical tampering.

Constructed from robust die-cast aluminum alloy with an integrated waterproof silicone sealing gasket, the HM-130 delivers exceptional outdoor durability across an operating temperature range of -40°C to +60°C. It features a multi-hole universal top plate compatible with major CCTV brands (such as Dahua, Hikvision, Uniview, and Amcrest), side threaded conduit entry knockouts, and a rear pass-through hole for through-wall cable routing. Finished in a durable matte white powder coating, it ensures long-term corrosion resistance and clean surface mounting on flat walls and ceilings.

Key System Features & Functionality

• Universal Multi-Pattern Mounting Base: Pre-drilled threaded patterns designed to match a wide variety of dome, turret, and bullet camera bases from multiple manufacturers.

• Deep 52 mm Profile: Generous internal cavity easily encloses bulky waterproof RJ-45 couplers, DC power connections, and excess cabling.

• Weatherproof Aluminum Alloy Construction: High-durability die-cast aluminum prevents moisture ingress, dust penetration, and environmental degradation.

• Concealed Cable Management: Enclosed cavity protects wiring connections from vandalism, accidental cuts, and UV exposure.

• Multi-Directional Cable Inlets: Features side threaded conduit access ports with removable plugs and a rear pass-through opening for clean through-wall installations.

• High Structural Load Capacity (4.5 kg): Safely supports camera hardware loads up to 4.5 kg (9.92 lbs) with high resistance to wind vibration.

• Extreme Climate Durability: Built to operate reliably in harsh outdoor climates from -40°C to +60°C.
