Full-Motion Single Monitor Desk Mount Bracket 13"–32" (High-Grade Steel & Structural Polymer, 360° Rotation, ±45° Tilt, 180° Swivel, Up to 8kg / 17.6lbs, C-Clamp & Grommet Base, Cable Management)

Product Overview

The KPM-300 is a commercial-grade single monitor articulating desk mount bracket, engineered for video surveillance command desks, security operations control stations, IT workstations, and commercial monitoring consoles. Designed to support flat or curved display monitors ranging from 13 inches up to 32 inches, this mount elevates the screen above the desktop surface to free up valuable workspace, streamline multi-camera viewing configurations, and provide complete ergonomic adjustment.

Constructed from heavy-duty structural high-grade steel combined with high-impact molded components and an anti-scratch powder-coated matte black finish, the bracket securely supports displays weighing up to 8 kg (17.6 lbs). The full-motion articulating arm delivers complete positional flexibility: 360° portrait-to-landscape screen rotation, ±45° vertical tilt adjustment to eliminate overhead light glare, and 180° horizontal swivel for multi-angle screen sharing. Equipped with dual versatile installation systems—a heavy-duty edge C-clamp and an integrated through-desk grommet base—the KPM-300 fits desktops up to 88 mm thick. It includes integrated cable routing channels along the arm and pole to keep power, HDMI, and video cables neatly organized. Standard VESA 75×75 mm and 100×100 mm mounting plates ensure plug-and-play compatibility with all standard surveillance monitors.

Key System Features & Functionality

• Broad Display Compatibility (13"–32"): Supports flat and curved surveillance and PC monitors measuring 13" to 32" diagonally.

• Full-Motion Articulation: Features 360° screen rotation (landscape/portrait orientation), ±45° downward/upward tilt, and 180° swivel for optimal line-of-sight positioning.

• Heavy-Duty 8 kg (17.6 lbs) Weight Capacity: Engineered with high-tensile structural steel and durable polymer fittings to prevent display drooping or wobbling.

• Universal VESA Compliance: Compatible with industry-standard VESA 75×75 mm and 100×100 mm bolt hole patterns.

• Dual Base Mounting Versatility: Includes both an edge-mounted heavy-duty C-clamp and an in-desk grommet bolt kit to accommodate various desk designs without permanent damage.

• Integrated Cable Management System: Detachable routing clips along the arm and vertical pole keep power cords, HDMI, and Ethernet cables organized and out of view.

• Ergonomic Desktop Space Saver: Suspends the display above the desk surface, liberating critical workspace for NVR mice, keyboards, and testing tools.

• Comprehensive Installation Hardware: Ships complete with desktop mounting clamps, grommet hardware, multi-size monitor screws (M4/M5), spacers, washers, and hex adjustment keys.
