10GBASE-LR SFP+ 1310nm Single Mode 10km Optical Transceiver Module (Duplex LC, DDM, MSA Compliant)

Product Overview

The LPOSFPLR01D 10GBASE-LR SFP+ Optical Transceiver Module is a carrier-class, hot-pluggable Small Form-Factor Pluggable Plus (SFP+) transceiver engineered for high-bandwidth 10-Gigabit Ethernet links, campus backbones, and enterprise data center aggregation. Operating at a nominal optical wavelength of 1310 nm over standard single mode fiber (SMF 9/125 µm), this module delivers wire-speed data throughput of 10.3125 Gbps across link distances reaching up to 10 kilometers (6.2 miles).

Equipped with a high-performance 1310 nm Distributed Feedback (DFB) laser and an ultra-sensitive PIN photodiode receiver, the LPOSFPLR01D terminates in an industry-standard Duplex LC optical connector. It integrates Digital Diagnostic Monitoring (DDM / DOM) per SFF-8472 specifications, allowing network administrators real-time diagnostic telemetry for laser bias current, transmitted optical power, received optical power, internal module temperature, and supply voltage. Housed in an all-metal zinc-alloy casing designed to minimize electromagnetic interference (EMI) and enhance heat dissipation, this MSA-compliant transceiver provides seamless interconnectivity across core enterprise switches, high-throughput firewalls, network storage arrays (SAN/NAS), and multi-gigabit IP surveillance backbones.

Key Features

• 10 Gbps High-Speed Throughput: Supports wire-speed 10GBASE-LR (10.3125 Gbps) and 10GBASE-LW (9.953 Gbps) optical communication protocols.

• 10 km Transmission Distance: Optimized for single mode OS1/OS2 optical fiber (9/125 µm) for links up to 10 kilometers without midspan amplification.

• Integrated DDM / DOM Diagnostics: Real-time monitoring of internal transceiver parameters (optical Tx/Rx power, temperature, voltage, laser bias) via I²C bus.

• 1310 nm DFB Laser & PIN Receiver: Ensures superior optical link budget, low jitter, and excellent chromatic dispersion tolerance.

• Duplex LC Optical Interface: Industry-standard compact LC duplex connector compatible with standard single mode patch cords.

• Hot-Pluggable SFP+ Footprint: Easy field installation and hot-swapping into active SFP+ switch ports without interrupting network traffic.

• All-Metal EMI-Shielded Casing: Heavy-duty zinc alloy construction provides maximum physical protection, passive thermal heat sinking, and low EMI radiation.

• Standards Compliance: Fully compliant with IEEE 802.3ae (10GBASE-LR), SFF-8431 (electrical interface), SFF-8472 (DDM), and Class 1 laser safety standards (IEC 60825-1).

Compatible Devices

• Managed Core & Aggregation Switches with 10G SFP+ uplink ports

• Enterprise Edge Routers, Next-Gen Firewalls, and Multi-Gigabit Gateways

• High-Capacity Network Video Recorders (NVRs) and VMS Storage Servers with 10GbE SFP+ Network Cards

• Storage Area Network (SAN) Switches, NAS Appliances, and PCIe 10GbE Network Interface Cards

• Single Mode OS2 LC-to-LC Duplex Fiber Optic Patch Cords (such as LPF13L10L1027L3M)
