- R5-2H – GVS Electronic Rim Lock (PIN Code & Mifare) R5-2H – GVS Electronic Rim Lock (PIN Code & Mifare)
- Description
- Key Technical Specifications
Product Overview
The R5-2H is a commercial and residential digital electronic rim lock (cerradura de sobreponer) manufactured under the GVS Security access hardware catalog. Purpose-built for exterior metal gates, perimeter iron doors, wooden main doors, and security enclosures, this surface-mount lock modernizes perimeter access where mortise installations or deep door cutting are not practical. Enclosed in a heavy-duty die-cast aluminum alloy body finished in Matte Black, it provides high physical resistance against forced entry and daily environmental exposure.
Engineered with multi-credential authentication, the R5-2H supports keyless entry via an illuminated touch numeric keypad (PIN code), high-frequency 13.56 MHz Mifare (MF) RFID smart cards/fobs, and a concealed mechanical key cylinder for emergency physical override (keys included). The digital controller features anti-peep virtual passcode technology, automatic deadbolt locking upon closure, low-battery alerts, and an exterior emergency USB power jump-start port. Powered by standard 6V DC alkaline batteries with optional 12V DC input support, the R5-2H delivers dependable standalone perimeter security for homes, commercial offices, and multi-tenant communities.
Key System Features & Functionality
-
Surface-Mounted Rim Design (Sobreponer): Installs directly on the face of metal gates, security grills, and wooden doors without mortise pocket prep.
-
Dual Digital Authentication (PIN + Mifare): High-responsiveness illuminated touch keypad for PIN codes plus integrated 13.56 MHz Mifare (MF) card reader.
-
Anti-Peep Virtual Passcode: Enter random digits before or after the genuine PIN code to prevent onlookers from identifying credentials.
-
Mechanical Key Emergency Override: Concealed cylinder keyway provides fail-safe physical access during complete battery depletion.
-
Heavy-Duty Aluminum Alloy Enclosure: Rugged die-cast aluminum front panel and reinforced steel rim chassis resist forced entry and tampering.
-
Auto-Locking Mechanism: Automatically drives the rim deadbolt into the locked position upon door closure.
-
Emergency USB Power Port: External 5V micro-USB / Type-C interface allows emergency jump-start via a portable power bank.
-
Dual Power Flexibility: Operates via internal 4 × AA batteries or supports hardwired 12V DC power for continuous installations.
| Parameter | Specification |
| Product Model / SKU | R5-2H |
| Brand / Line | GVS Security |
| Product Type | Standalone Electronic Rim Lock (Cerradura Inteligente de Sobreponer) |
| Lock Form Factor | Surface-Mount Rim Deadbolt / Latch |
| Finish / Color | Industrial Matte Black |
| Chassis Material | Solid Die-Cast Aluminum Alloy & Heavy-Duty Galvanized Steel |
| Access Methods | Digital PIN Code, 13.56 MHz Mifare (MF) Card & Mechanical Backup Key |
| Card Reader Frequency | 13.56 MHz (Mifare Classic / Desfire compatible) |
| User Capacity | Up to 100 User Credentials (PIN codes + Mifare cards) |
| PIN Code Length | 4 to 10 Digits |
| Keypad Type | Touch-sensitive acrylic panel with integrated white LED backlighting |
| Anti-Peep Security | Random decoy digit entry before/after genuine PIN supported |
| Mechanical Keyway | Concealed high-security cylinder with physical backup keys |
| Emergency Power Port | Micro-USB / USB-C 5V DC emergency input port |
| Applicable Door Types | Metal gates, wrought iron grills, steel doors, wooden doors |
| Applicable Door Thickness | 30 mm to 65 mm (1.18" to 2.56") |
| Door Handing Compatibility | Reversible (Universal for left-hand and right-hand swing doors) |
| Operating Power | DC 6V via 4 × 1.5V AA alkaline batteries (or external DC 12V terminal) |
| Battery Lifespan | Approximately 10–12 months (based on 10 operations per day) |
| Low Voltage Alarm | Audible warning beeps and LED flash below 4.8V DC |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Operating Relative Humidity | 10% to 90% RH (Suitable for sheltered outdoor gates and indoor doors) |
| Exterior Unit Dimensions | Approx. 160 mm × 65 mm × 25 mm |
| Interior Rim Unit Dimensions | Approx. 135 mm × 100 mm × 40 mm |
| Total Net Weight | Approx. 1.50 kg (3.30 lbs) |
