Wi-Tek WI-PS210H V3 8-Port Fast Ethernet PoE Switch with Dual Uplinks (65W Budget / 250m Extend Mode)

The Wi-Tek WI-PS210H V3 is an updated, high-density 10-port Fast Ethernet PoE switch engineered for commercial IP surveillance networks and small-to-medium office deployments. Outfitted with 8 10/100Mbps PoE ports supporting IEEE 802.3af/at standards alongside 2 dedicated 10/100Mbps RJ45 uplink ports, it allows installers to connect to a central Network Video Recorder (NVR) and an internet router simultaneously without sacrificing camera ports.

Delivering a 65W total PoE power budget (up to 30W per port), the V3 revision features a hardware DIP switch for 250-meter Extend Mode, enabling stable PoE power and video transmission across long-distance cable runs up to 820 feet at 10Mbps. Built-in port isolation (VLAN mode) optimizes video traffic by preventing broadcast storms between IP cameras, while integrated 6kV surge protection safeguards connected edge hardware from lightning and electrical voltage spikes.

Key System Advantages

• High-Density 8 PoE + 2 Uplink Layout: Combines 8 PoE ports for IP cameras with 2 dedicated RJ45 uplink ports for simultaneous NVR and router connectivity.

• 250m Extended Surveillance Reach: Hardware DIP switch enables Extend Mode to supply PoE power and data over long cable drops up to 250 meters (820 ft).

• Port Isolation (VLAN Mode): Isolates PoE ports 1–8 from each other to block broadcast storms and prevent camera network congestion.

• IEEE 802.3af/at PoE Compliance: Delivers up to 30W on individual ports with a 65W total power budget for IP cameras and network hardware.

• 6kV Surge Protection: Integrated electrical protection guards connected edge equipment against lightning strikes and power surges.

Technical Specifications
