HM-1602B – Heavy-Duty Aluminum Gooseneck Wall Mount Bracket for PTZ Cameras (305 mm x 180 mm x 95 mm / 12" x 7.08" x 3.74")

Product Overview

The HM-1602B (Dimensions: 305.0 mm x 180.0 mm x 95.0 mm / 12.0" x 7.08" x 3.74") is a heavy-duty outdoor and indoor aluminum gooseneck wall mount bracket engineered specifically for Speed Dome, PTZ (Pan-Tilt-Zoom), and large pendant dome security cameras. Designed for commercial, industrial, and perimeter video surveillance installations, this bracket extends the camera 305 mm away from structural walls, providing an unobstructed field of view to eliminate architectural blind spots across building facades, parking structures, and perimeter perimeters.

Constructed from rugged die-cast aluminum alloy with an integrated rubber sealing gasket, the HM-1602B delivers superior structural stability with a high load-bearing capacity of up to 10.0 kg (22.05 lbs). It features an internal hollow channel for completely concealed, weather-protected cable routing, a safety tether hook for secure camera servicing, and standard G1-1/2" threaded pendant neck mounting. Finished in a corrosion-resistant matte white powder coating, it ensures reliable long-term performance across an operating temperature range of -40°C to +60°C.

Key System Features & Functionality

• Extended 12-Inch Gooseneck Reach: Projects cameras 305 mm out from the wall to deliver a wide, unobstructed panoramic viewing angle.

• Heavy-Duty Aluminum Alloy Construction: High-strength die-cast aluminum prevents structural deflection, rust, and physical tampering under demanding conditions.

• High Load Capacity (10 kg): Engineered to support large, motorized PTZ speed domes and heavy camera housings up to 10.0 kg (22.05 lbs) with high wind-load resistance.

• Concealed Internal Cable Channel: Hollow gooseneck arm routes video, power, and data cables internally, protecting wiring from UV degradation, moisture, and vandalism.

• Standard G1-1/2" Threaded Interface: Features standard pendant coupling with set screws, ensuring broad compatibility with major industry PTZ and dome camera housings.

• Integrated Safety Cable Hook: Built-in metal tether point provides drop prevention and hands-free support during installation and routine maintenance.

• Extreme Weather Durability: Operates reliably in harsh commercial environments across a wide temperature range of -40°C to +60°C.
