6-Port Gigabit PoE Switch (4× Gigabit PoE+ Ports 65W + 2× Gigabit SFP Uplink Slots)

Product Overview

The LP-SG642FP Gigaspeed PoE Switch is a high-performance commercial Ethernet switch designed for high-definition IP video surveillance, enterprise wireless networks, and VoIP deployments. Featuring four (4) independent 10/100/1000 Mbps RJ45 Gigabit PoE/PoE+ ports alongside two (2) dedicated 1.25 Gbps Gigabit SFP optical uplink slots, this switch delivers a non-blocking 16 Gbps switching fabric (backplane) that ensures seamless data transmission without bottlenecks.

Compliant with IEEE 802.3af and IEEE 802.3at standards, the LP-SG642FP provides up to 30W per port with an aggregate total PoE power budget of 65W, allowing users to power high-draw IP cameras, PTZ domes, wireless access points, and IP intercoms directly over standard Cat5e/Cat6 network cabling. The dual SFP cages provide flexible long-distance fiber uplink connectivity (up to 20 km using single-mode optical transceivers), making it an ideal aggregation switch for multi-building campuses, perimeter CCTV rings, and structured cabling network racks.

Key Features

• Full Gigabit Port Density: Equipped with 4× 10/100/1000Base-T PoE+ RJ45 ports and 2× 1000Base-X SFP optical cages for high-bandwidth uplinks.

• IEEE 802.3af/at PoE+ Support: Delivers up to 30W per port with automatic device detection (Auto-Sensing) to prevent damage to non-PoE equipment.

• 65W Total PoE Power Budget: Ample power capacity to concurrently run multiple IR bullet cameras, indoor turrets, access control readers, and VoIP phones.

• Non-Blocking 16 Gbps Backplane: Wire-speed Store-and-Forward switching architecture with Jumbo Frame support ensures zero-latency transmission of 4K video streams.

• VLAN Port Isolation Mode: Integrated DIP switch toggle enables hardware port isolation to suppress broadcast storms and bolster cyber-physical network security.

• Dual Fiber SFP Flexibility: Facilitates long-distance optical interconnects back to core switches or NVR storage racks using standard SFP modules (such as LPOSFPLX03D).

• Industrial-Grade Metal Housing: Heavy-duty, fanless silent metal enclosure designed for efficient passive cooling, desktop placement, or wall/rack mounting.

Compatible Devices

• IP Surveillance Cameras (4K, PTZ, Dome, Turret, and Bullet Cameras)

• 1.25G Gigabit SFP Optical Transceivers (such as LPOSFPLX03D 1310nm 20km)

• Single Mode and Multimode Duplex LC Fiber Patch Cords (such as LPF13L10L1027L3M)

• Network Video Recorders (NVRs) and VMS Surveillance Servers

• IP Access Control Panels (such as C2-260) and Biometric Standalone Readers (such as F19ID)

• High-Performance Wireless Access Points (AP) and IP Telephony (VoIP) Systems
