Lysora 28-Port Gigabit Smart Cloud-Managed PoE+ Switch (370W Budget, 1U Rackmount)-LCS-24GS-P

Product Overview

The Lysora LCS-24GS-P is a high-density 28-port full Gigabit smart cloud-managed PoE+ network switch engineered to act as a robust aggregation and core power-delivery backbone for enterprise IP surveillance systems, large Wi-Fi access point clusters, VoIP networks, and smart commercial facilities. It features 24 X 10/100/1000 Mbps RJ45 PoE+ downlink ports compliant with IEEE 802.3af/at (up to 30 W per port) supported by an expansive 370 W dedicated PoE power budget, alongside 2 X Gigabit RJ45 dedicated uplink ports and 2 X Gigabit SFP optical uplink slots for high-speed copper aggregation and extended fiber backhaul.

Engineered with software-controlled ePoE (extended PoE) transmission up to 250 meters, an automated PoE Watchdog self-healing mechanism that reboots unresponsive edge cameras, and unified cloud management (Lysora Cloud Portal, Mobile App, and Web GUI), the LCS-24GS-P eliminates unnecessary maintenance site visits. Encased in a heavy-duty 19-inch 1U rackmount steel housing with smart single-fan active cooling and integrated ±6 kV surge / ±4 kV ESD protection, it provides non-stop, high-reliability Layer 2 network switching.

Key System Features & Functionality

• 28-Port Full Gigabit Architecture: Features 24 X Gigabit PoE+ downlink ports, 2 X Gigabit RJ45 uplinks, and 2 X Gigabit SFP slots for high-bandwidth fiber and copper data aggregation.

• 370 W Total PoE+ Budget: Powers up to 24 cameras, access control terminals, or Wi-Fi APs simultaneously with up to 30 W per port compliant with IEEE 802.3af/at.

• Software-Controlled ePoE & PoE Watchdog: Enables long-distance power and data delivery up to 250 m (at 10 Mbps) and real-time PD monitoring that automatically power-cycles frozen devices.

• Unified Cloud, App & Web Management: Remote multi-site configuration, port power scheduling, VLAN segmentation (802.1Q), and bandwidth management via Lysora Cloud Portal, Mobile App, and Web GUI.

• ±6 kV Surge & ±4 kV ESD Protection: Hardware-level protection safeguards internal electronics and connected edge devices from electrical spikes and lightning transients.

• 19-Inch 1U Rackmount Steel Chassis: Rugged metal enclosure with smart single-fan active cooling designed for standard 19-inch equipment racks and server cabinets.
