R6-5 – Biometric Electronic Rim Lock (Fingerprint, PIN & Card)

Product Overview

The R6-5 is an enterprise and residential multi-credential biometric electronic rim lock (cerradura digital de sobreponer) distributed under the GVS Security access hardware catalog. Purpose-built for perimeter metal gates, wrought iron grills, apartment entrance doors, commercial backrooms, and utility enclosures, this surface-mount lock modernizes boundary security without requiring complex mortise pocket preparations or hollow-core modifications. Enclosed in an ultra-slim aluminum alloy and ABS escutcheon finished in Matte Black, it provides high physical resistance against forced tampering and environmental wear.

Engineered with quad-authentication flexibility, the R6-5 supports instant biometric recognition via an integrated semiconductor capacitive fingerprint sensor (FPC), keyless numeric access via an illuminated touch keypad (PIN code), proximity entry via high-frequency RFID smart cards (Mifare 13.56 MHz / ID), and a concealed physical mechanical key cylinder for manual emergency override. Advanced security logic features anti-peep virtual password masking, motorized auto-locking upon door closure, tamper acoustic warning alarms, and a 5V micro-USB emergency power jump-start interface. Powered by standard 1.5V AA alkaline batteries, the R6-5 delivers versatile, keyless perimeter protection for high-security residential and commercial doorways.

Key System Features & Functionality

• Quad-Access Authentication: Unlocks via biometric fingerprint, digital PIN passcode, RFID smart card, and mechanical emergency override keys.

• Swedish FPC Semiconductor Fingerprint Sensor: High-precision capacitive scanner delivers rapid biometric verification (< 0.5 seconds) with high spoof resistance.

• Surface-Mounted Rim Architecture (Sobreponer): Installs directly onto the interior/exterior surface of exterior metal gates, grills, and wooden doors without mortise cutting.

• Anti-Peep Virtual Code Masking: Enter random decoy numbers before or after the true PIN to prevent credentials from being spied on by bystanders.

• High-Capacity Credential Storage: Accommodates up to 100 registered fingerprints, 100 RFID proximity cards, and 10 user PIN codes with a master administrative PIN.

• Automated Motorized Lock Body: Heavy-duty motorized rim bolt extends automatically upon door closure for reliable auto-locking.

• External Emergency Jump-Start Port: 5V micro-USB port on the underside of the exterior unit allows instant backup power using a portable power bank during battery exhaustion.

• Tamper & Failed-Attempt Lockout: Emits an acoustic alarm and temporarily freezes operation after multiple consecutive unauthorized access attempts.
