100M STRENGTHENED CABLE 22 AWG 4 STRANDED CCA CORES

Product Overview

The SF2204LE-100M Reinforced Multi-Conductor Cable is a cost-effective, high-flexibility signal and low-voltage power cable engineered for commercial access control, intrusion alarms, intercoms, and public address installations. Supplied on a compact 100-meter (328-foot) spool, this cable features four (4) color-coded 22 AWG stranded conductors composed of high-grade copper-clad aluminum (CCA), delivering the optimal balance of electrical conductivity, mechanical flexibility, and budget optimization for medium-distance edge device connections.

Engineered for dependable wire pulling through conduits, riser pathways, and suspended ceiling grids, the SF2204LE-100M is reinforced with an internal high-tensile nylon rip cord that protects the insulated conductors from excessive pulling tension and simplifies outer jacket stripping without nicking the inner wires. Each conductor is insulated with durable, color-coded PVC (Red, Black, White, Green) to ensure error-free circuit identification during termination. Encased in a rugged, flexible flame-retardant white PVC outer sheath, it provides dependable physical protection against abrasion and bending fatigue when wiring PIR motion sensors, magnetic door contacts, keypad readers, and exit push-buttons.

✅ Key Features

• 4-Core 22 AWG Configuration: Standard multi-conductor layout ideal for running combined DC power and dry/wet signal loops in security environments.

• Stranded CCA Conductors: Copper-Clad Aluminum stranded cores offer high wire flexibility for effortless corner routing and terminal block hookups while reducing total installation cost.

• 100-Meter Reel Packaging (328 ft): Convenient job-length spool ideal for commercial technicians, reducing cut waste on small-to-medium security runs.

• Internal Tensile Reinforcement: Embedded nylon rip cord absorbs mechanical pull stress during conduit installation and enables quick, clean jacket stripping.

• Color-Coded Conductor Insulation: Distinct Red, Black, White, and Green wire jackets eliminate cross-wiring mistakes on access control and alarm control panels.

• Flame-Retardant PVC Jacket: Protective outer insulation resists flame spread, mechanical abrasion, and common construction chemicals.

• Sequential Foot/Meter Markings: Printed jacket counter markings allow installers to accurately monitor remaining spool length and track usage per run.

Compatible Devices

• Multi-Door Networked Access Control Panels (such as C2-260) and Wiegand / OSDP Card Readers

• Standalone Biometric & RFID Terminals (such as F19ID and SpeedFace series)

• Hardwired PIR Motion Detectors, Glass Break Sensors, and Seismic Detectors

• Magnetic Door Contacts (Surface and Recessed Reed Switches)

• Request-to-Exit (REX) Push Buttons and Emergency Door Releases

• 12V DC Centralized Access Control Power Supplies (such as the DC12V-5A UPS unit)

• Intercom Sub-Stations, Door Chimes, and Low-Voltage Audio Buzzers
